BlitzNXT 36V 150Ah Golf Cart Lithium iron Battery

  • High Capacity & Voltage: 150Ah at 38.4V nominal, for extended outings with minimal recharges.
  • Strong Performance: 150A max discharge/charge for agile handling and rapid recovery.
  • Long Cycle Life: ≥4000 cycles at 0.2C rate, for durable, cost-saving reliability.
  • IP65 Waterproof Rating: Shields against dust and water for versatile outdoor use.
  • Compact Design: 55kg weight, black iron box, 490*440*265mm for effortless integration.
  • Bluetooth BMS: Protects against overcharge, overdischarge, overcurrent, and temperature fluctuations with app monitoring.
Contact Us

Free worldwide shipping on all orders over $50

  • 30 days easy returns
  • Order yours before 2.30pm for same day dispatch
Guaranteed Safe Checkout

BlitzNXT 36V 150Ah Golf Cart Lithium iron Battery
BlitzNXT 36V 150Ah Golf Cart Lithium iron Battery

[wpforms id=”1190″ title=”true” description=”Request a call back”]

Safety & Maintenance

Safety essentials: No water immersion, short-circuiting, or extreme heat exposure. Store at 40-60% SOC in a cool, dry place (10-30°C); recharge every 3 months at 30A for 3-4 hours. Full charge prior to first use. Safe for road, rail, sea, or air transport.

BMS Protection Features

  • Overcharge Protection: Triggers at 3.65V/cell (43.8V overall), recovers at 3.35V/cell (40.2V overall).
  • Overdischarge Protection: Triggers at 2.5V/cell (30V overall), recovers at 3.0V/cell.
  • Overcurrent Protection: Charging limit 160A (2s delay), Discharge limit 400A (10s delay).
  • Temperature Protection: Charging high: 55°C, low: 0°C; Discharge high: 60°C, low: -20°C.
  • Capacity Alarm: Alerts at 5% SOC, recovers at 10%.

Applications

  • Golf Carts: 150Ah capacity and 150A max discharge power full-day rounds, with fast charging to keep you on the green longer.
  • Utility Vehicles: IP65 rating withstands rain and dirt for campus or resort transport in -20°C to 50°C extremes.
  • Leisure & Neighborhood EVs: Bluetooth BMS allows app-based tracking for seamless, maintenance-light use in communities or parks.
  • Daily Short-Haul Trips:490*440*265mm fits compactly; ≥4000 cycles minimize swaps for sustainable commuting.
  • Eco-Upgrade Option: 60kg design enhances vehicle efficiency, replacing heavy lead-acid for greener, quieter rides.
Item Standard Remark
Specification 38.4V/150Ah 1P12S
Nominal voltage 38.4V
Capacity 150Ah
Minimum capacity 145Ah 0.2C(30A) discharge
2.0V/CELL
Size (L*W*H) 490*440*265mm
Weight About 55Kg
Standard discharge 30A
Max Discharge current 120A SOC:20%-100%
0℃-50℃
Discharge cut-off voltage 34V
Charge voltage 43.2V
Standard charge 30A
Max Charge current 100A SOC:0%-80%
25℃-45℃
Resistance ≤30mΩ
Charge temperature range 0~45℃
Discharge temperature range -20~50℃
Storage temperature range 10~30℃
Storage humidity 5%~90%
Charge Discharge interface ACTB-135
Mode of communication CAN/RS485
Waterproof Rate IP65
Shell material Black iron box
Cycle life ≥4000 time Operating conditions:
25℃±2℃
0.2C/0.2C
Other Bluetooth

Additional information

Weight 121 lbs
Dimensions 19.29 × 17.32 × 10.43 in
Nominal Voltage

38.4V
Capacity

150Ah
Standard Discharge

30A
