Safety & Maintenance
Store the battery at 40–60% SOC in a clean, dry, and ventilated environment. Recharge for 5–6 hours every three months during long-term storage. Avoid water immersion, short circuits, mechanical impact, and exposure to extreme heat. Suitable for road, rail, sea, and air transportation with proper packaging.
BMS Protection Features
- Overcharge Protection: Cell-level protection at 3.65V, pack-level at 29.2V.
- Overdischarge Protection: Cell cut-off at 2.5V, pack cut-off at 20V.
- Overcurrent Protection: 100A charging and 400A discharging protection thresholds.
- Temperature Protection: High/low temperature protection during charge and discharge.
- Capacity Alarm: Low SOC alarm at 5%, recovery at 10%.
Applications
- Electric Utility & Industrial Vehicles: Supports high-current discharge for heavy-duty operation.
- Energy Storage Systems: Suitable for backup and off-grid 25.6V battery systems.
- Industrial Equipment: IP67 rating ensures reliability in dusty, humid, and vibration-prone environments.
- Specialized Power Systems: Long cycle life and robust housing reduce maintenance and downtime.
| Parameter | Value | Notes |
|---|---|---|
| Nominal Voltage | 25.6V | Li-ion battery pack |
| Capacity | 230Ah | Minimum 230Ah @ 0.2C (46A) |
| Dimensions (L × W × H) | 662 × 650 × 195 mm | – |
| Weight | Approx. 105 kg | – |
| Standard Discharge Current | 115A | – |
| Max Discharge Current | 175A | – |
| Discharge Cut-off Voltage | 20V | – |
| Charge Voltage | 29.2V | – |
| Standard Charge Current | 36A | – |
| Internal Resistance | ≤30 mΩ | – |
| Charge Temperature Range | 0°C ~ 45°C | – |
| Discharge Temperature Range | -20°C ~ 50°C | – |
| Storage Temperature Range | 10°C ~ 30°C | Humidity 5%–90% |
| Charge/Discharge Interface | ANDERSON 175 | – |
| Waterproof Rating | IP67 | – |
| Cycle Life | ≥2000 cycles | 25°C, 0.2C |
